| Rated Capacity KVA |
Voltage Combination | Vector group | Off-load Loss(W) | On-load Loss(W) (120℃) |
Short Circuit current(%) | Impendance (%) |
||
| High Voltage (KV) |
Tapping Range (%) |
Low Voltage (KV) |
||||||
| 50 | 30 35 38.5 |
±5 or ±2×2.5 |
0.38 0.4 0.415 0.433 |
Dyn11 or Yyn0 |
450 | 1420 | 2.3 | 6.0 |
| 100 | 630 | 2090 | 2.0 | |||||
| 160 | 790 | 2810 | 1.5 | |||||
| 200 | 880 | 3320 | 1.5 | |||||
| 250 | 990 | 3800 | 1.3 | |||||
| 315 | 1170 | 4510 | 1.3 | |||||
| 400 | 1370 | 5410 | 1.1 | |||||
| 500 | 1620 | 6650 | 1.1 | |||||
| 630 | 1860 | 7690 | 1.0 | |||||
| 800 | 2160 | 9120 | 1.0 | |||||
| 1000 | 2430 | 10400 | 0.75 | |||||
| 1250 | 2830 | 12700 | 0.75 | |||||
| 1600 | 3240 | 15400 | 0.75 | |||||
| 2000 | 3820 | 18200 | 0.75 | |||||
| 2500 | 4450 | 21800 | 0.75 | |||||
